CommercialLift 2-Post 40,000 lb
Class 4 through Class 7 commercial trucks.
$15,999
40,000 lb 2-post commercial lift for Class 4–7 trucks. 440V 3-phase, 72-inch rise, 14-foot ceiling requirement. Installation included.
- 40,000 lb rated capacity
- Class 4–7 commercial vehicle range
- 440V 3-phase power unit
- 72-inch rise in 60 seconds
- 10” I-beam columns with reinforced floor anchors
- 8”-diameter arm saddles
- 6 sets of adapter pads included
- Factory installation and commissioning included
✓ In Stock — Ships in 5-10 business days
The CommercialLift 2-Post 40,000 lb handles medium-duty and heavy-duty commercial vehicles from Class 4 box trucks to Class 7 semi-trailers — the range that most shops turn away because their lift won’t handle it. The overhead-beam design uses 10” I-beam columns with reinforced floor anchors rated for full-rated dynamic loads. Symmetric arm configuration with 8”-diameter arm saddles reaches under the widest commercial frames. The 440V 3-phase power unit raises 40,000 lbs to 72” in 60 seconds. Comes with 6 sets of adapter pads for different frame profiles. Requires 14’ ceiling clearance. Factory installation and commissioning included in price.
| Rise | 72 inches |
| Power | 440V 3-phase, 5 HP |
| Capacity | 40,000 lbs |
| Warranty | 5 years structural, 2 years parts + labor |
| Vehicle Class | Class 4–7 (medium/heavy duty) |
| Overall Height | 192 inches |
| Column Material | 10” I-beam steel |
| Arm Saddle Diameter | 8” |
| Ceiling Requirement | 14’ (168”) |
| Drive-Through Width | 152 inches |
How does this compare?
This is the entry point for serious commercial fleet service. If you service box trucks, step vans, straight trucks, or medium-duty semis, this is the lift. The 3-phase power requirement is the gating factor — most shops already have 3-phase if they’re doing commercial work. Factory installation means it’s certified and in compliance on day one.
