CoachLift RV 4-Post Platform Lift 15,000 lb
Class A through Class C. Full access, front to rear.
$12,999
15,000 lb RV/motorhome platform lift. 240-inch runways, Class A–C clearance, 42-inch service height, dual power units with equalization.
- 15,000 lb rated capacity
- 240” runways (longest production motorhomes)
- 84” wide platform
- 42” service height — full underbelly access
- Dual 220V power units with cable equalization
- Approach ramps rated 8,500 lbs per axle
- Rear-heavy load equalization system
- Side technician walkways included
✓ In Stock — Ships in 5-10 business days
The CoachLift RV is a 15,000 lb 4-post drive-on platform lift built specifically for motorhomes and recreational vehicles — the Category that destroys ordinary shop lifts. Class A motorhomes on Freightliner or Spartan chassis, Class B and Class C units — the CoachLift handles all of them. The 240” runways accommodate the longest production motorhomes. 84” wide platform clears the overhang of slide-outs (retracted). Platform height of 42” gives full access to chassis components, drivetrain, and underbelly systems. Dual 220V power units with cable equalization prevent tilt under the rear-heavy weight distribution common in motorhomes. Approach ramps rated to 8,500 lbs per axle.
| Power | Dual 220V single-phase, 2 HP each |
| Capacity | 15,000 lbs |
| Warranty | 5 years structural, 2 years power units |
| Unit Weight | 4,200 lbs |
| Equalization | Cable-driven |
| Platform Size | 240” x 84” |
| Vehicle Class | Class A, B, C motorhomes |
| Service Height | 42” |
| Approach Ramp Rating | 8,500 lbs per axle |
How does this compare?
RV chassis service is fundamentally different from passenger vehicles. The overhang, weight distribution, and wheelbase make standard lifts a liability. The CoachLift is designed around actual RV chassis specs — 240” runways cover everything from a Class C on a Ford E-350 to a 45’ Class A diesel pusher. The equalization system handles the rear-heavy weight distribution that comes standard with a slide-out coach.
